Advantage:Strong tensile strength, long-life,little elongation,easy to trough, anti-bent, suitable for long distance, heavy load
and high-speed conveying materials.
Use: Conveying materials in coal, mine. harbour, metallurgy, power station,chemical etc.field.
Type:(1) Conventional, Fire-resistant, Cold-resistant, Abrasion-resistant,Heat-resistant, Acid/alkali-resistant etc.(Refering
rubber cover)(2) General structure, Cross rigid structure, Anti-tearing iron ring structure.
| |
ST630 |
ST800 |
ST1000 |
ST1250 |
ST1600 |
ST2000 |
ST2500 |
ST3150 |
ST3500 |
ST4000 |
ST4500 |
ST5000 |
ST5400 |
ST6000 |
| Elongation Tensile Strength (N/mm) |
630 |
800 |
1000 |
1250 |
1600 |
2000 |
2500 |
3150 |
3500 |
4000 |
4500 |
5000 |
5400 |
6300 |
| Max.Diameter of Cord (mm) |
3.0 |
3.5 |
4.0 |
4.5 |
5.0 |
6.0 |
7.5 |
8.1 |
8.6 |
8.9/9.1 |
9.7 |
10.9 |
11.3 |
12.3 |
| Top Rubber Cover Thickness(mm) |
10 |
10 |
12 |
12 |
12 |
12 |
15 |
15 |
15 |
15/17 |
16 |
17 |
17 |
18 |
| Bottom Rubber Cover Thicknees (mm) |
5 |
5 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
8/8 |
8 |
8.5 |
9 |
10 |
| Reference oweight (mm) |
5 |
5 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
8/8 |
8 |
8.5 |
9 |
10 |
| Reference weight (kg/ ㎡) |
18 |
19.5 |
21.5 |
22.2 |
26.1 |
33.1 |
35.3 |
41.1 |
45 |
45/45 |
51 |
59 |
62 |
65 |
| Width(mm) |
Cord Number |
| 800 |
75 |
75 |
63 |
63 |
63 |
63 |
50 |
50 |
50 |
|
|
|
|
|
| 1000 |
95 |
95 |
79 |
79 |
79 |
79 |
64 |
64 |
64 |
64/65 |
59 |
55 |
55 |
54 |
| 1200 |
113 |
113 |
94 |
94 |
94 |
94 |
76 |
76 |
77 |
77/68 |
71 |
66 |
66 |
63 |
| 1400 |
133 |
133 |
111 |
111 |
111 |
111 |
89 |
89 |
90 |
90/79 |
84 |
78 |
78 |
74 |
| 1600 |
151 |
151 |
126 |
126 |
126 |
126 |
101 |
101 |
104 |
104/91 |
96 |
90 |
90 |
85 |
| 1800 |
|
171 |
143 |
143 |
143 |
143 |
114 |
114 |
117 |
117/103 |
109 |
102 |
102 |
96 |
| 2000 |
|
|
159 |
159 |
159 |
159 |
128 |
128 |
130 |
130/114 |
121 |
113 |
113 |
107 |
| 2200 |
|
|
|
|
|
176 |
141 |
141 |
144 |
144/125 |
134 |
125 |
125 |
118 |
| 2400 |
|
|
|
|
|
193 |
155 |
155 |
157 |
157/137 |
146 |
137 |
137 |
129 |
| 2600 |
|
|
|
|
|
209 |
168 |
168 |
170 |
170/148 |
159 |
149 |
149 |
140 |
| 2800 |
|
|
|
|
|
|
|
|
184 |
184/160 |
171 |
161 |
161 |
151 | |
Rubber cover thickness and density decide the belt weight.
Note:100-1500m Per Roll.
Belt beyonds the above specification, can also be made as required .Technical Data for GX STEEL CORD CONVEYOR BELT Belt.
Technical Data for GX STEEL CORD CONVEYOR BELT Belt
| |
GX630 |
GX800 |
GX1000 |
GX1250 |
GX1600 |
GX2000 |
GX2500 |
GX3000 |
GX3500 |
GX4000 |
GX4500 |
GX5000 |
GX5500 |
GX6000 |
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
(N/mm)
Elongation Tensile strength |
630 |
800 |
1000 |
1250 |
1600 |
2000 |
2500 |
3000 |
3500 |
4000 |
4500 |
5000 |
5500 |
6000 |
|
(mm)
Max.Diameter Cord |
4.5 |
4.5 |
4.5 |
4.5 |
6.0 |
6.0 |
7.2 |
8.3 |
8.7 |
9.1 |
9.7 |
10.9 |
11.3 |
12.3 |
(mm)
Pitch of Cord |
20 |
17 |
13.5 |
11 |
20 |
16 |
17 |
18 |
18 |
17 |
16 |
17 |
17 |
18 |
|
(mm)
Thickness |
19 |
19 |
19 |
19 |
23 |
23 |
27 |
28 |
28 |
29 |
30 |
30 |
32 |
32 |
(kg/m2)
Reference Weight |
23.9 |
21.3 |
25 |
25.7 |
32.2 |
33.7 |
40.2 |
41.9 |
43.6 |
46.6 |
49.8 |
51.8 |
55.9 |
57.9 |
(mm)
Width
|
Cord Number |
| 800 |
38 |
45 |
56 |
69 |
38 |
47 |
44 |
43 |
|
|
|
|
|
|
| 1000 |
48 |
56 |
70 |
87 |
48 |
60 |
56 |
53 |
53 |
56 |
60 |
56 |
56 |
54 |
| 1200 |
|
68 |
86 |
104 |
58 |
72 |
68 |
64 |
64 |
68 |
72 |
68 |
68 |
63 |
| 1400 |
|
|
100 |
122 |
66 |
84 |
78 |
74 |
74 |
79 |
84 |
79 |
79 |
74 |
| 1600 |
|
|
116 |
140 |
76 |
95 |
90 |
86 |
96 |
101 |
107 |
103 |
103 |
96 |
| 1800 |
|
|
127 |
157 |
86 |
108 |
102 |
96 |
96 |
101 |
107 |
103 |
103 |
96 |
| 2000 |
|
|
142 |
173 |
96 |
120 |
113 |
107 |
107 |
113 |
120 |
114 |
114 |
107 |
| 2200 |
|
|
|
|
|
132 |
125 |
118 |
118 |
125 |
133 |
125 |
125 |
118 |
| 2400 |
|
|
|
|
|
146 |
117 |
129 |
129 |
137 |
146 |
137 |
137 |
129 |
| 2600 |
|
|
|
|
|
158 |
148 |
140 |
140 |
148 |
158 |
148 |
148 |
140 |
| 2800 |
|
|
|
|
|
170 |
160 |
151 |
151 |
160 |
170 |
160 |
160 |
151 | |
| Type |
Standard and Main Technical |
|
※ Conventional |
GB/T9970 DIN22131 |
|
※※ Fire-resistant |
MT668 HG2539 DIN22131 |
| Conventional Flame Retardant |
HG2539 |
| Heat Resistant |
HG/T2297 ISO4195 |
| Abrasion Resistant |
Shore Abrasion≤90mm3 |
| Heat & abrasion Resistant |
Resistant≤125≤125℃,Shore Abrasion≤150mm3 |
| Acid,alkali,oil resistant |
HG4-846 |
| Cold-resistant |
Fragility Temperature-50℃ |
| Oione-resistant |
Oione Density 50X10 40℃/72h No Chap | |
Min.Conveyor Roller Diameter
| Type |
ST630 |
St800 |
St1000 |
ST1250 |
ST1600 |
ST2000 |
ST2500 |
ST3150 |
ST3500 |
ST400 |
ST4500 |
ST5000 |
ST5400 |
ST600 |
MIn.conveyor roller diameter
￠(mm) |
800 |
1000 |
1250 |
1400 |
1600 |
1800 |
2000 | |
ST series are produced by GB/T 9770 standard,GX series by LuQ/Qd439 standard.
FLame retardant is equal to Fire Resistant
Application: Widely Used in coal industry and mines etc.for
conveying materials.
Construction: Lay our transversely steel bars along the belt.
Fill rubber compound into each place between bars.Then
wrapped these bars with skimmed fabric to form the
reinforcement.On the top and bottom of the bars,covered
with a layer of rubber compound.Feature: The belt runs by means of the traction of steel cable.Belt
itself only supports conveying materials, not bears pulling strength.Belt
rigidity is big with little elongation.Belt is of impact resistant and
anti-abrasion. It is suitable for conveying materials under a long
distance and with heavy load . |
|
|
Belt Size
|
Size of steet bar (mm) |
Size of steet bar(mm)
|
pitch of steel bars(mm)
|
Remark
|
|
864X2PX（4.5+5+2.5） |
5X5X840 |
28.0 |
35、45、55、65 |
|
|
926X2PX（3+5+2） |
5X5X880 |
30.0 |
50 |
|
|
1055X2PX（3+5+2） |
5X5X1034 |
28.5 |
35、45、55 |
|
|
1070X2PX（3+5+1.5） |
5X5X1034 |
40.0 |
35、45、55 |
|
|
1070X2PX（3+5+1.5） |
5X5X1034 |
40.0 |
35、45、55 |
|
|
1070X2PX（3+5+1.8） |
5X5X1034 |
40.0 |
35、45、55 |
|
|
1070X2PX（3+5+2） |
5X5X1034 |
28.5 |
35、45、55 |
|
|
1070X2PX（3+5+2） |
5X5X1034 |
28.5 |
35、45、55 |
|
|
1090X2PX（5+5+5） |
5X5X1055 |
40.5 |
35、45、55 |
|
|
1126X2PX（3+5+2） |
5X5X1080 |
40.0 |
35、45、55 |
|
|
1126X2PX（3+5+3） |
5X5X1080 |
40.0 |
50 |
|
|
1290X2PX（3+6+3） |
6X6X1250 |
40.0 |
40 |
|
|
1290X2PX（5+6+2） |
6X6X1250 |
37.0 |
38 |
|
|
1290X2PX（5+6+2.6） |
6X6X1250 |
37.0 |
36 |
|
|
1300X2PX（5+7+5） |
7X7X1250 |
40.5 |
40 |
|
|
Calculating method(m2)： m2=Width(m)X[Ply Number+ ]xLength(m)+Ear Rubber Concertion(m2)
